Managing severe non-invasive ventilation (NIV) needs requires precision equipment engineered for adaptive respiratory support. Patients suffering from Chronic Obstructive Pulmonary Disease (COPD), restrictive lung disease, Obesity Hypoventilation Syndrome (OHS), or neuromuscular disorders often require advanced Bilevel Positive Airway Pressure (BiPAP) machines that adapt to changing lung mechanics.
The ResMed Lumis 150 VPAP ST is widely recognized across Pakistani pulmonology centers as a gold-standard non-invasive ventilator. Featuring IntelligentAir technology, iVAPS (intelligent Volume-Assured Pressure Support), and built-in wireless data connectivity, it delivers tailored ventilation. This guide provides a detailed overview of the ResMed Lumis 150 specifications, pricing benchmarks across Pakistan, clinical setting parameters, and local stock availability in Multan, Lahore, and Islamabad. Contact now For detail
1. Clinical Overview: ResMed Lumis 150 vs. Lumis 100 VPAP ST
Understanding the difference between the Lumis 100 and Lumis 150 series helps families select the device prescribed by their physician:
- ResMed Lumis 100 VPAP ST: Designed for standard bi-level therapy, delivering set IPAP (Inspiratory Positive Airway Pressure) and EPAP (Expiratory Positive Airway Pressure) with fixed Spontaneous/Timed backup rates.
- ResMed Lumis 150 VPAP ST: Incorporates iVAPS, an advanced mode that automatically adjusts pressure support to maintain target alveolar ventilation even as the patient’s respiratory effort fluctuates during different sleep stages.
2. ResMed Lumis 150 Specifications & Technology Stack
The Lumis 150 non-invasive ventilator utilizes several proprietary algorithms to maximize patient-ventilator synchrony:
- iVAPS (intelligent Volume-Assured Pressure Support): Target ventilation is continuously monitored. If patient breathing weakens, the machine automatically increases pressure support to meet target tidal volume.
- AutoEPAP Feature: Keeps the upper airway open by automatically adjusting expiratory pressure in response to partial or full obstructions.
- iBR (intelligent Backup Rate): Maximize spontaneous breathing while providing a safety net of back-up breaths only when needed.
- Vsync & TiControl: Vsync compensates for unintentional mask leaks instantly, while TiControl allows the clinician to set minimum ($Ti\text{ Min}$) and maximum ($Ti\text{ Max}$) inhalation time limits.
- Integrated Wireless (ResMed Lumis 150 VPAP ST 4G): Features built-in cellular connectivity (4G/3G) to upload daily therapy compliance data automatically to ResMed AirView for physician monitoring.
- ClimateControl AirSense Humidification: Heated HumidAir water chamber coupled with ClimateLineAir heated tubing prevents condensation (rainout) and nasal dryness.
3. ResMed Lumis 150 VPAP ST Price in Pakistan (2026 Market Matrix)
The ResMed Lumis 150 VPAP ST price in Pakistan varies based on condition (brand-new imported vs. refurbished units), included accessories (Heated Tubing, Humidifier, Mask), and vendor warranty support.
| Machine Condition & Configuration | Estimated Price Range (PKR) | Package Inclusions |
| Brand New / Boxed (Local Warranty) | PKR 260,000 – 320,000 | Lumis 150 device, HumidAir chamber, ClimateLineAir tubing, Mask, 4G module, 1-2 Year Warranty |
| Imported Boxed Pack (International Warranty) | PKR 160,000 – 250,000 | Lumis 150 device, integrated humidifier, power brick, travel bag, setup titration |
| Certified Refurbished / Low-Hour Units | PKR 40,000 – 150,000 | Pre-owned machine (sanitized, motor stress tested), basic tubing, non-heated humidifier |
For related sleep apnea equipment or rental options, explore our complete catalog on #.
4. Understanding ResMed VPAP ST Settings & Clinical Modes
The Lumis 150 includes 5 primary therapy modes configured by a qualified pulmonologist or respiratory therapist:
- iVAPS Mode: Primary mode for volume-assured ventilation; maintains target alveolar ventilation.
- ST (Spontaneous/Timed) Mode: The machine follows the patient’s natural inhalation, but if the patient stops breathing for a set interval, it initiates a breath at the set Backup Rate (BPM).
- S (Spontaneous) Mode: Augments each breath initiated by the patient.
- T (Timed) Mode: Delivers machine-triggered breaths at a fixed rate set by the doctor.
- CPAP Mode: Constant positive pressure for standard obstructive sleep apnea.
5. Stock & Delivery Availability: Multan, Lahore & Islamabad
Fast equipment delivery is critical when patients are discharged from ICU or ward care. Authorized delivery networks across Pakistan offer specialized home setup:
- Multan Delivery: Direct doorstep delivery and technician setup serving Nishtar Road, Multan Cantt, Bosan Road, and Shalimar Colony.
- Lahore Distribution: Express delivery within 4 to 6 hours across Johar Town, DHA, Gulberg, Model Town, and Mayo Hospital commercial corridors.
- Islamabad & Rawalpindi: Dedicated biomedical technicians cover Blue Area, Saddar, F-Sectors, G-Sectors, and Bahria Town, offering on-site pressure configuration and clinical trials.
Patients requiring simultaneous oxygen supplementation alongside BiPAP therapy can review oxygen concentrators via #.
6. Downloading the ResMed Lumis 150 VPAP ST User Manual & Setup Guide
Proper maintenance ensures longevity and precise air delivery:
1.Reviewing the User Manual:Step 1.
Refer to the official ResMed Lumis 150 VPAP ST user manual provided in the box to understand menu navigation, clinical access key combinations, and cleaning schedules.
2.Accessing Clinical Settings Menu:Step 2.
To enter clinical parameter adjustments, press and hold both the Dial button and the Home button simultaneously for 3 seconds until the Clinical Menu displays on the screen.
3.Connecting Tubing & Water Chamber:Step 3.
Fill the HumidAir chamber with distilled water up to the max line and slide it into the side compartment. Connect the ClimateLineAir heated tube to the rear outlet.
4.Daily & Weekly Hygiene Maintenance:Step 4.
Wash the silicone mask cushion daily using warm water and mild soap. Clean the water chamber weekly and inspect the rear foam filter monthly for dust accumulation.
Frequently Asked Questions (FAQs)
What is the price of a brand-new ResMed Lumis 150 VPAP ST in Pakistan?
A brand-new, boxed ResMed Lumis 150 VPAP ST with an integrated humidifier, heated tube, mask, and local warranty typically ranges between PKR 260,000 and PKR 320,000. Refurbished or imported units without local warranty start lower.
What is the difference between Lumis 150 VPAP ST and ST-A?
The ST model provides standard non-invasive bi-level ventilation. The ST-A model adds clinical-grade safety alarms (for power disconnects, low volume, and oxygen drops), making it suited for highly dependent ventilator patients.
